Best : KEX3090CMSS Wall Mount Chimney Hood : 35 7/16-In

Mouse Over Main Image to Zoom In

• Seamless, multi-faceted construction in brushed stainless steel
• Powerful yet quiet internal and external blowers with HVI certified performance
• Quick release stainless steel/aluminum mesh filters are dishwasher safe
• Two-level halogen lighting
• Electronic controls include a 10 minute time-delay shut-off feature and a reminder light for filter maintenance
• Heat Sentry is a smart feature that detects excessive heat and adjusts speed to high automatically
• Telescopic flue for 8 ft. to 9 ft. ceilings - Custom extensions available
• 4-speed push-button controls are tastefully hidden from view
• Halogen lights illuminate the cooktop surface brilliantly. Two
• lamps are on the 36 in. model, and three on the 48 in. model.
• See Accessories Tab for External and In-Line Blower options

Dimensions
Width (in.)	35 7/16
Depth (in.)	22
Height including Flue (min.-max.) (in.)	33 - 44
Height of Hood (in.)	9 13/16
Width of Flue (in.)	9 7/8
Depth of Flue (in.)	9 1/2
(Distances over 30" are at the installer's and user's discretion)
8 foot Ceiling (in.)	24 - 28
9 foot Ceiling with Flue Extension (in.)	28 - 30
10 foot Celing (in.)	27 - 30
Product Specifications
Finishes	304 Grade Brushed Stainless Steel
Lighting	(2) Halogen - MIR16
Lighting Levels	2
Controls	4-Speed Electronic Push Button
Feature	Heat Sentry, Delay Off and Filter Timer
Remote	N/A
Filter	Stainless Steel Mesh
Optional Filters	N/A
Backsplash	N/A
Flue Extension (Vented Applications Only)	FEXTK30SS
Deco Trim	N/A
Liners	N/A
Shelves	N/A
Mechanical Specifications
Blower	Exterior, In-line
Performance (CFM)	EB6 - 600; EB9 - 900; EB12 - 1200; EB15 - 1500; ILB3 - 280; ILB6 - 600; ILB9 - 800; ILB11 - 1100
Sones	N/A
HVI	Yes
Electrical Amps @ 120 Volts	6.7 max.
Electrical Connection	Direct
Duct Size	8-in. Round (Damper/Adapter is included with the product in the duct size indicated)
Duct Direction	Vertical
Non-Ducted Capability - Recirculating Flue	No
Non-Ducted Capability - Recirculating Kit	N/A
