Designed with a
dual-flame sealed burner, this cooktop offers the widest range of BTU
performance in the industry for the utmost versatility - from a roaring
18,000-BTU boil to a gentle 450-BTU simmer.
Continuous Grates
Designed for cooking multiple
dishes at varying temperatures on a single cooktop.
These grates
allow easy movement of even the heaviest pots and pans from burner to
burner - without lifting.
Flex-2-Fit
System
Premium gas cooktop versatility with sealed burners.
Premium
performance accessories include an available grill/griddle, an optional
wok ring, and a simmer plate to use with small cooking utensils.
Easy-to-Clean Design
Deep-well
cooktop and sealed burners are designed for easy cleaning.
Dimensions & Weights
Width:
30"
Depth:
20 7/8"
Height (Extreme Bottom to Underside of Cooktop):
4 1/2"
Cutout Width:
27 1/4" min./28 1/2" max.
Cutout Depth:
19 1/8" min./19 3/4" max.
Cutout Height:
8"
Approx. Shipping Weight:
75 lbs.
Features
Deep-Well Formed Cooktop:
Yes
Professional-Grade Burner Controls:
Yes
Continuous Grates:
Yes
Min-2-Max Dual-Flame Sealed Burner:
1 - 18,000 to 450 BTU
Sealed Power Burner:
1 - 12,000 BTU
Sealed Precision Burner:
1 - 9,500 BTU
Sealed Precision Burner:
1 - 7,500 BTU
Sealed Precision Burner:
1 - 5,000 to 875 BTU
Linear Flow Burner Valves:
Yes
Electric Pilotless Ignition:
Yes
A.D.A. Compliant:
Yes
Accessories
Granite Countertop Installation Kit:
Optional - PN# 903103-9010
Grill/Griddle:
Available - PN# 318251614
Wok Ring:
Optional - PN# 318254309
Simmer Plate:
Optional - PN# 318254206
LP Gas Conversion Kit:
Included
Specifications
Color:
Stainless Steel
Gas/Power Supply Connection Location:
Right Rear
Voltage Rating:
120V/60 Hz/15A
Connected Load (kW Rating) @ 120 Volts:
.001 kW (For use on adequately wired 120V,
dedicated circuit having 2-wire service with a separate ground wire)
Electrical Cable:
Yes
Amps @ 120 Volts:
1.0 Amps
Approved for Single Oven Combination
Installation:
