Viking DEDO530SS 30" Designer Series Premiere Electric Double Oven


Part Number: DEDO530SS

30" Double Electric Wall Oven with Vari-Speed Dual Flow, TruConvec Convection, Rapid Ready Preheat, Gourmet-Glo Infrared Broiler and TimePiece Clock: Stainless Steel

Viking DEDO530SS


Part Number: DEDO530SS

Our Viking sales territory includes NY, NJ, PA, DE, and WV. For more details call us at 877-679-2686.

Why shop evVive.com?
  • Authorized Dealer
  • Experienced Sales Team
  • Factory Trained Installers
  • Competitive Package Deals

Today's Price$5099.00
Still Need Help? Call 877-679-2686

  • Commercial-Type Cooking Power
  • Largest oven cavity in the industry makes room for all your cooking needs
  • Patent-pending Vari-Speed Dual Flow convection system has the largest fan in the industry; the 8 1/2" two-speed fan works bi-directionally for maximum airflow and excellent cooking results
  • Concealed 10-pass dual bake element makes the oven cavity easy to clean while providing precise temperatures
  • Rapid Ready Preheat provides one of the fastest preheat times so your oven is ready to begin cooking when you are
  • Each oven has six porcelain-coated rack positions and comes standard with three oven racks
  • Improved halogen lighting makes it easy to see inside
  • Extra large Gourmet-Glo glass enclosed infrared broiler provides superior broiling performance and maximum coverage
  • High performance cooking modes include TruConvec convection cooking, convection roast, convection bake, convection broil, conventional bake, and three-level conventional broil
  • TimePiece digital/analog clock has won multiple prestigious design awards
  • Set the oven to begin cooking up to 24 hours later and shut off when cooking time is complete with the Timed Bake feature
  • Heavy-duty broiler pan and tray with additional rack provides more roasting and broiling options
  • Meat probe offers perfect baking/roasting of fine meats
  • TruGlide full extension racks allow for easy access
  • Self-clean feature on all ovens
  • Easy Operation and Cleanup
  • Self-clean oven setting with indicator light
  • Ergonomically designed handle for superior feel
  • High-density insulation contains heat within the oven cavity for maximum energy savings and performance, even during high-temperature self-cleaning
  • Durable control knobs made of solid stainless steel
  • Exclusive Finishes
  • Available in Stainless Steel (SS), Black (BK), White (WH), Biscuit (BT), Stone Gray (SG), and Graphite Gray (GG)
  • May be ordered with Brass Trim Option (BR) for handle, knobs, and buttons
  • All brass components have a durable, protective coating for maintenance-free normal use
  • Warranty Highlights
  • One-year full - complete product
  • Five-year limited - oven tubular and infrared burners, and electric elements
  • Ten-year limited - porcelain oven(s) and porcelain inner door panel(s)
  • Ninety-day limited - cosmetic parts such as glass, painted items, and decorative items
  • Additional Cooking Accessories Available Under "Accessories"
Our Viking sales territory includes NY, NJ, PA, DE, and WV. For more details call us at 877-679-2686.
Specifications
Upper Oven Volume (AHAM Standard)4.1 Cu. Ft.
Upper Oven Volume (Total)4.8 Cu. Ft.
Lower Oven Volume (AHAM Standard)4.1 Cu. Ft.
Lower Oven Volume (Total)4.8 Cu. Ft.
Bake Wattage3500 Watts
Broil Wattage4000 Watts
Electrical Requirements4-Wire Ground, 240 VAC, 50 Amp Electrical Connection. Unit Equipped with No.10 Ground Wire in Unit. Fuse Separately.
Maximum Amp Usage240V 40.0 Amps, 208V 34.7 Amps
Approximate Shipping Weight449 Lbs. (203.7 kg)
Overall Dimensions
Overall Width29 1/2" (74.9 cm)
Overall Height51 3/4" (131.4 cm)
Overall Depth to Edge of Door25 11/16" (65.2 cm)
Overall Depth with Door Open46" (116.8 cm)
Cutout Dimensions
Cutout Width28 1/2" (72.4 cm)
Cutout Height50 5/8" (128.6 cm)
Cutout Depth24" (61.0 cm)
Interior Oven Dimensions
Interior Width - Both Ovens25 7/16" (64.6 cm)
Interior Height - Both Ovens16 1/2" (41.9 cm)
Interior Depth - Upper Oven16 13/16" (42.7 cm)
Interior Depth - Lower Oven16 13/16" (42.7 cm)
