Exclusive TriTemp Storage System provides three independent temperature zones
Electronic Control Center constantly monitors and maintains the set temperature in each zone within 1.5 degrees F (.83 degrees C)
Exclusive glass control pad
Shelving/Capacity
15 shelves accommodate up to 150 full-size wine bottles horizontally, keeping corks moist
Solid maple facings may be finished to coordinate with surrounding cabinetry
Protection
Maintains constant 60% humidity level
Ultraviolet-resistant tempered glass and black interior protects wine from harmful light
Lower zone has raised maple facings to add additional ultraviolet protection
Low-intensity interior lighting
High-temperature and open-door alarms may be connected to a home security system
Keyed lock on door for extra security
Easy Maintenance and Cleanup
Fully removable shelves for easy cleaning
Removable upper grille
Power interruption switch completely turns off power to unit for safe cleaning and light tube replacement
Front venting sealed refrigeration system works silently and efficiently
Adjustable-height lower kickplate removes to provide easy access to evaporator pan
Professional-Style Construction
Design and basic dimensions provide built-in appearance with standard cabinetry
Dual-magnet/spring assist door seal system automatically closes wine cellar door
Door stops are factory set at 110 degree swing; easily adjust to 90 or 120 degree swing
Must be ordered either right or left hinge
Custom Front Features
Blend seamlessly into cabinetry with locally supplied front panels; customer may purchase Viking Professional Series or Designer Series handles, or opt for custom handles
Fully integrated depth allows wine cellar to fit flush with countertops or cabinet and drawer fronts
Concealed trim capability - the wine cellar can be fully integrated with no visible cabinet trim exposed
Concealed hinges allow product to be hidden with no mechanical devices exposed
Finish Options
Available in a clear or fluted glass door
Accessories Available
Professional Series handle kit (PHK26)
Designer Series handle kit (DHK25)
Stainless steel side panels (DSSP2, DSSPR2)
Stainless steel top kit (TOP-30)
Warranty Highlights
Two-year full covers complete unit
Six-year full - sealed refrigeration system
Twelve-year limited - sealed refrigeration system (includes compressor, condenser, dryer/strainer, evaporator, and connecting tubing)
Ninety-day limited - cosmetic parts such as glass, painted items, and decorative items
Our Viking sales territory includes NY, NJ, PA, DE, and WV. For more details call us at 877-679-2686.
Specifications
Electrical Requirements
115 Volt, 60 Hz, 15 Amp Dedicated Circuit; 3-Wire Cord With Grounded 3-Prong Plug Attached to Product
Maximum Amp Usage
2.0 Amps
Approximate Shipping Weight
525 Lbs. (236.3 kg)
Total Capacity
150 Bottles
Total Shelves
15
Temperature Zones
3
Overall Dimensions
Width
30" (76.2 cm)
Min. Height from Bottom
82 1/2" (209.6 cm)
Max. Height from Bottom
84 3/4" (212.7 cm)
Depth from Rear to Edge of Side Trim
23 13/16" (60.5 cm)
Depth from Rear to Edge of Cabinet Side Trim
24 3/4" (62.9 cm)
Depth from Rear to Edge of Door Trim
24" (61.0 cm)
Cutout Dimensions
Width
30" (76.2 cm)
Min. Height
82 7/8" (210.5 cm)
Max. Height
83 3/4" (212.7 cm)
Depth
25" (63.5 cm) - Can be installed in 24" (61.0 cm) deep openings; door faces and top grille will protrude 3/4" (1.9 cm) into room.
