Multi-Level Power Wash
Multi-level washing with two stainless steel wash arms.
Five-Stage Filtration and Waste Removal System - Exclusive.
Prevents redeposit of food particles to deliver spot free dishes.
Removable coarse strainer.
Triple-Clean filtration - Exclusive.
Ultra-hard food waste disposer.
Sure-Temp water heating - Exclusive.
Automatically heats water to appropriate/selected temperature, assuring excellent washing results.
1,200 watt HydroFlo water heater.
Operable with "cold" ground water (50°F).
Condensate Quick Dry
Moisture condenses on the cooler stainless steel tank and door and drains to sump area.
Quick and efficient drying.
Quiet Clean Performance Package
Engineered top to bottom for the quietest operation possible.
Separate motor/pump assemblies for washing and draining.
Sound absorbing/heat retaining insulation.
"Load-As-You-Like" Sturdi-Bilt Racks
Accommodates 13 international place settings of china in a single load.
Fully usable and removable nylon coated racks.
One-piece silverware/cutlery basket.
Lower Rack.
Upper Rack.
Additional Construction and Safety Features
Diamond-Brite stainless steel tank and inner door - brightly polished to protect long-term appearance - Exclusive.
Largest dishwasher tank/door.
Rigid steel braces.
Completely enclosed rustproof steel base/pan with removable front.
Fill and drain system.
Door triple safety system - mechanical latch, electrical safety switch, and start button.
Cycles/Options
Cycles - Pots/Pans, Normal Wash, Econo/China, Rinse/Hold.
Options - Hi Temp Wash, Delay Start up to 4 hours.
Energy Star Qualified.
CEE Tier I Super Efficient.
Installation Accessories
Professional Door Panel - PDDP24
Professional Door Panel with Louvers - PDDPL24SS
Designer Door Panel - DDDP241
Professional Handle Kit - PHK23
Designer Handle Kit - DDHK23
Exclusive Finishes
PDDP24/DDDP241 door panels available in Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG), Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM),
Lemonade (LE), Sage (SA), Mint Julep (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR), Burgundy (BU), Plum (PL), Chocolate (CH), Cobalt Blue (CB).
PDDPL24 door panel available in stainless steel (SS).
Warranty Highlights
One-year full covers complete dishwasher (two-years with certified installation).
Lifetime limited covers tank and inner door.
Five-year limited covers electronic controls, racks, motor/pump assemblies, and water distribution system.
Ninety day limited - cosmetic parts such as glass, painted items and decorative items.
Available at evVive.
www.evVive.com
Our Viking sales territory includes NY, NJ, PA, DE, and WV. For more details call us at 877-679-2686.
Specifications
Electrical Requirements
15.0 Amps, 120VAC/60 Hz; Power cord must be purchased separately.
Water-Heating Element Rating
1,200 Watts
Inlet Water Temperature
120°F (49°C) Recommended; Dishwasher Will Perform Properly with Cold Water; Note: Cycle Times Will Vary
Inlet Water Pressure Operating Range
10 to 125 psi (.69 to 8.62 Bar)
Inlet Water Hose
5' (1.5m) Braided Stainless Steel Water Line with 3/8" (0.95cm) Compression Fitting Connected to Dishwasher
Drain Hose
7' (2.13m) 1/2" (1.3cm) ID "Crimp-Proof" Flexible Drain Hose Attached to Dishwasher, Connections Provided for 5/8" (1.6cm), 3/4" (1.9cm) or 1" (2.5cm), Cut as Required
FDB200 is a standard capacity dishwasher that uses 293 kWhr/yr and has an estimated yearly operating cost of $32.49.
Your operating costs will depend on your utility rates and use. The estimated operating cost is based on 4 washloads a week and a 2011 national average electricity cost of 11.09 cents per kWh. For more information, visit
