Switch-activated vent door opens only during drying for quieter operation.
All key operating components cushion-mounted for quiet operation.
Blue LED power on light in kickplate indicates cycle is operating.
"Load-As-You-Like" Sturdi-Bilt Racks
Accommodates 15 international place settings of china in a single load.
Fully useable and extendable nylon coated racks.
Two-piece silverware/cutlery basket allows separate placement in various lower or upper rack locations.
Lower Rack.
Roller Bearing Upper Rack
Additional Construction and Safety Features
Diamond-Brite stainless steel tank and inner door.
Largest dishwasher tank/door.
Rigid steel braces.
Completely enclosed rustproof steel base/pan with removable front.
Fill and drain system - Exclusive.
Door triple safety system.
Cycles/Options
Cycles - Pots/Pans, Normal Wash, Econo Wash, Light/China, Rinse/Hold.
Options - Econo Dry, 155°F Final Rinse, Top Wash Only, Delay Start - up to 10 hours.
Warranty Highlights
One-year full covers complete dishwasher (two-years with certified installation).
Lifetime limited covers tank and inner door.
Five-year limited covers electronic controls, racks, motor/pump assemblies, and water distribution system.
Ninety day limited - cosmetic parts such as glass, painted items and decorative items.
Our Viking sales territory includes NY, NJ, PA, DE, and WV. For more details call us at 877-679-2686.
Specifications
Electrical Requirements
15.0 Amps, 120VAC/60 Hz; 5' (1.8m) Electrical Cord 3 Prong Plug Supplied with Unit
Water-Heating Element Rating
1,400 Watts
Inlet Water Temperature
120°F (49°C) Recommended; Dishwasher Will Perform Properly with Cold Water; Note: Cycle Times Will Vary
Inlet Water Pressure Operating Range
10 to 125 psi (.69 to 8.62 Bar)
Inlet Water Hose
5' (1.5m) Braided Stainless Steel Water Line with 3/8" (0.95cm) Compression Fitting Connected to Dishwasher
Drain Hose
7' (2.13m) 1/2" (1.3cm) ID "Crimp-Proof" Flexible Drain Hose Attached to Dishwasher, Connections Provided for 5/8" (1.6cm), 3/4" (1.9cm) or 1" (2.5cm), Cut as Required
Drain Hose High Loop Required
Height from Floor - 20" (51.0cm) Min.
Approx. Shipping Weight
157 Lbs. (70.7 kg)
Dimensions
Overall Width
23 7/8" (60.6 cm)
Overall Depth from Rear - To Edge of Side
24" (61.0 cm) - Includes Door Panel
Overall Depth from Rear with Door Open
49" (124.5 cm)
Overall Height from Floor
33 7/8" (86.0 cm) Min. - 35" (89.0 cm) Max.
Cutout Width
24" (61.0 cm)
Cutout Height
34" (86.4 cm) Min. - 35" (89.0 cm) Max.
Cutout Depth
24" (61.0 cm)
Note
This unit is NOT designed to be installed without a trim. All dimensions include trim.
VDB450 is a standard capacity dishwasher that uses 340 kWhr/yr and has an estimated yearly operating cost of $37.71.
Your operating costs will depend on your utility rates and use. The estimated operating cost is based on 4 washloads a week and a 2011 national average electricity cost of 11.09 cents per kWh. For more information, visit
