Exclusive VSH (VariSimmer-to-high) Pro Sealed burner System.
Exclusive VariSimmer setting for all burners.
Exclusive all burners equipped with SureSpark Ignition System for consistent and reliable ignition.
New! - Heavy-duty metal knobs with stainless steel finish shipped standard.
Right and Left Oven Features
Exclusive patented Vari-Speed Dual Flow convection system has the largest convection fan in the industry.
Concealed 10-pass dual bake element provides precise temperature control.
Extra large Gourmet-Glo glass enclosed infrared broiler provides superior broiling performance.
Rapid Ready Preheat System provides one of the fastest preheat times so your oven is ready to begin cooking when you are.
Oven has six porcelain coated rack supports and comes standard with two standard oven racks and one TruGlide full extension oven rack.
Three strategically located oven lights provide maximum visibility.
Heavy-duty broiler pan and tray provide more roasting and broiling options.
High performance cooking modes include Bake, Convection Bake, TruConvec Convection Cooking, Convection Roast, Hi, Med and Low Broil, Convection Broil, and Self-Clean.
Easy Operation and Cleanup
Exclusive - one-piece porcelainized cooking surface for easy cleanup.
Burner caps are easily removable for quick cleaning.
Heavy-duty, porcelainized, cast-iron removable surface grates provide continuous front-to-rear, left-to-right surface for easy movement of large pots.
New! - one-piece control panel assembly easily removable for convenient front access to surface burner valves, switches, spark modules, and door lock assembly.
New! - front serviceable oven electronic control board.
Griddle/Simmer Plate
Commercial-grade, machined steel construction with Blanchard finish to retain cooking oils for stick-resistant cooking.
Thermostatically controlled for precise temperatures.
New! - cast aluminum grease trough holds 2-1/2 cups of liquid and can be easily removed from the front of the griddle for cleaning.
Char-Gril
Automatic electric spark ignition/re-ignition.
New! - porcelainized, cast-iron one-piece grate.
Porcelainized flavor generator plates catch dripping and circulate smoke around food for outdoor grilled flavor.
Exclusive - two-piece porcelainized drip pan can hold three quarts of liquid.
Drip tray located beneath the burner catches any possible drippings not caught in the drip pan.
Finish Details
Available in Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG), Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM), Lemonade (LE),
Sage (SA), Mint Julep (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR), Burgundy (BU), Plum (PL), Chocolate (CH), Cobalt Blue (CB).
May be ordered with Brass Accent Option (BR)
Available at evVive.
www.ajmadsion.com
MFG SKU VDSC560-6GQSS
Our Viking sales territory includes NY, NJ, PA, DE, and WV. For more details call us at 877-679-2686.
Burner Ratings
Grated Burners (Each)
15,000 BTU Nat./12,500 BTU LP (4.4 kW/3.7 kW)
TruPower Plus Burner (Front Right)
18,500 BTU Nat./16,600 BTU LP (5.4 kW/4.9 kW)
Griddle (Each)
15,000 BTU Nat./12,500 BTU LP (4.4 kW/3.7 kW)
Grill
18,000 BTU Nat./16,000 BTU LP (5.3 kW/4.7 kW)
Others
Electrical Requirements
240-208 VAC, 60 Hz Electrical Connection Box on Product, Connect with Locally Supplied 3-Wire, Flexible Cord or "Pigtail" Rated 50 Amp 125-250 VAC Minimum. Cord Must Be Agency Approved for Use with Household Electric Ranges.
Maximum Amp Usage
240V - 40.0 Amps, 208V - 34.7 Amps
Gas Requirements
Shipped Natural Gas Standard; Convert to LP/Propane Factory Installed; Accepts Standard Residential 1/2" ID Gas Service Line
