Stainless steel surface burners with electric spark ignition accommodate an infinite range of settings
VariSimmer setting, found on each surface burner, provides gentle, even simmering across the entire cooking vessel surface, even at extra-low heat levels - without the use of unconventional on/off or small center devices
Automatic electric spark re-ignition; surface burners light in any position on the knob and re-light if extinguished, even on lowest setting
Right oven - extremely large convection oven
Left bake oven
Natural airflow baking with dual 15,000 BTU burners; more power for quicker heatup and even heat distribution
1,500 degree F, closed-door, Gourmet-Glo infrared broiling with 18,000 BTU burner (right oven only )
Four fan-forced convection oven functions
All convection modes utilize the ProFlow Convection Air Baffle, which is specifically designed to ensure balanced airflow for even heat distribution
Heavy-duty, porcelain broiler pan/grid
Two oven lights with control panel switch in large oven; one oven light in small oven
Convection fan switch on control panel
Oven "on" indicator light
Commercial-style bezels around control panel knob
Griddle/Simmer Plate - 24" wide
Commercial-grade, machined steel construction
Commercial-type, blanchard finish holds cooking oils for stick-resistant cooking
Thermostatically controlled for precise temperature
24" wide griddle includes separate burner controls
Control panel light indicates desired temperature has been reached
Removable grease pan for easy cleanup
Safe, Easy Operation
Large, easy-to-read knobs with childproof, push-to-turn safety feature
Heavy-duty oven door handle
Automatic electric spark ignition - no standing pilot to re-light, waste energy, or add extra heat to the kitchen
10" by 11" heavy-duty, porcelainized, cast-iron, removable surface burner grates provide virtually continuous front-to-rear, left-to-right surface for easy movement of large pots
Stainless steel landing ledge with solid, welded, seamless finish
Efficient insulation contains heat within the oven cavity for energy savings and performance
Removable pull-out drip tray with roller-bearing glides for smooth operation
Installation Accessories Available
6" high, stainless steel backguard (R48BG6)
10" high, stainless steel backguard (R48BG10)
Stainless steel high-shelf (R48HS24)
Stainless steel island trim (R48TII)
Stainless steel countertop side trim (R27CST)
Curb base front in stainless steel (R48CBF) conceals range legs
Caster/Quick Connection Kit (CKR)
Exclusive Finishes
Available in Stainless Steel (SS), Black (BK), White (WH), Almond (AL), Biscuit (BT), Stone Gray (SG), Graphite Gray (GG), Burgundy (BU), Lemonade (LE), Mint Julep (MJ), Forest Green (FG), Viking Blue (VB), Cobalt Blue (CB), and Eggplant (EP)
May be ordered with Brass Trim Option (BR) for nameplate, window trim, door handle/brackets, drip tray pull, knob bezels, thermal-convection switch bezel, and grate support side trim
Warranty Highlights
One-year full covers complete product
Five-year limited - surface burners and oven tubular burner
Ten-year limited - porcelain oven and porcelain inner door panel
Ninety-day limited - cosmetic parts such as glass, painted items, and decorative items
Additional Cooking Accessories Available Under "Accessories"
Our Viking sales territory includes NY, NJ, PA, DE, and WV. For more details call us at 877-679-2686.
Burner Ratings
Surface Burner Rating
15,000 BTU Nat./13,500 BTU LP (4.4 kW/4.0 kW)
Griddle Burner Rating
15,000 BTU Nat./12,500 BTU LP (4.4 kW/3.7 kW)
Broil Rating
18,000 BTU Nat./16,000 BTU LP (5.3 kW/4.7 kW)
Right Oven Bake Rating
Two 15,000 BTU ea. Nat./LP (Two 4.4 kW ea.)
Left Oven Bake Rating
One 15,000 BTU ea. Nat./LP (One 4.4 kW ea.)
Others
Electrical Requirements
120 VAC/60 Hz; 4 Ft. (121.9 cm), 3-Prong Plug Attached to the Unit
Maximum Amp Usage
19.6 Amps
Gas Requirements
Shipped Natural Gas Standard; Convert to LP/Propane Factory Installed
