Zephyr CPAE48ASX

Mouse Over Main Image to Zoom In

• Stainless Steel Baffle Filters
• Electronic Touch Controls
• 3 Speeds
• 15 Min. Delay-Off
• 2 Halogen Lamps, GU10 50W
• Dual Level Lighting
• Ambient Lighting, 40W T29
• 8" Round Vertical Ducting
• 3-1/4" x 10" or 8" Round Horizontal Ducting

Performance
Internal Blower	600 CFM, 9 Sones
External Blower	1000 CFM
Features
Controls	Electronic Touch
Speed Levels	3
Delay-Off	Yes
Halogen Lighting	50W x 2
Incandescent Lighting	40W x 2
Dual-Level Lighting	Yes
Filters	Baffle x 3
Recirculating	No
Duct Cover Extension	N/A
Specifications
Internal Blower Vertical Ducting	8"
Internal Blower Horizontal Ducting	3 1/4" x 10"
External Blower Vertical Ducting	8" - 10"
External Blower Horizontal Ducting	8" - 10"
AC Input	120V - 60Hz
Internal Blower AC Power	Max. 630W at 5.25 Amps
External Blower AC Power	Max. 880W at 7.33 Amps
Dimensions
Width	48"
Depth	24 1/2"
Height	28 1/2"
Min. Vertical Ducting Height Accomodations	Min. Ceiling Height 7'8". Hood Mounted 28" Above Cooking Surface; 64" From Floor.
Max. Vertical Ducting Height Accomodations	Max. Ceiling Height 8'10". Hood Mounted 36" Above Cooking Surface; Hood Mounted 72" From Floor.
Horizontal Ducting Height Accomodations	Min. 28" - Max. 36" From Cooking Surface.

Accessories

Documents & Manuals
