Zephyr ZVEE42AS

Mouse Over Main Image to Zoom In

• 715 CFM
• 6 Sones Max.
• 6 Speeds
• Touch Controls
• Halogen Lamps, GU10 50W
• Dual Level Lighting
• 15 Minute Delay-Off
• Ductless Recirculating Kit (Optional)
• Wire Spice Rack (Optional)
• 6" Round Vertical Ducting
• Stainless Back Splash (Optional)
• MFG SKU ZVE-E42AS

Performance
Internal Blower	715 CFM
Internal Blower Sones	6
Features
Controls	Electronic Touch
Speed Levels	6
Delay-Off	Yes
Lighting	Halogen, 50W x 4
Dual-Level Lighting	Yes
Filters	Metal Mesh x 3
Recirculating	Optional
Duct Cover Extension	Yes, Up to 14 Ft. Ceiling
Specifications
Ducting	6" Round Vertical
AC Input	120V - 60Hz
AC Power	Max. 550W at 4.6 Amps
Dimensions
Width	42"
Depth	24"
Min. Height Ducted	32 1/2"
Min. Height Recirculating	36"
Max. Height	51"
Min. Mounting Height Ducted	Min. Ceiling Height 8'. Hood Mounted 28" Above Cooking Surface; 64" From Floor.
Max. Mounting Height Ducted	Max. Ceiling Height 10'3". Hood Mounted 36" Above Cooking Surface; 72" From Floor.
Min. Mounting Height Recirculating	Min. Ceiling Height 8'4". Hood Mounted 28" Above Cooking Surface; 64" From Floor.
Max. Mounting Height Recirculating	Max. Ceiling Height 10'3". Hood Mounted 36" Above Cooking Surface; 72" From Floor.
